BREAKING NEWS in the fat bike world...

HED's entire line of Big Deal fat rims can now be purchased as a rim-only for the custom build of your dreams!

Our more discerning customers just weren’t satisfied with an 85mm carbon rim. The bikes keep getting wider, the tires keep getting larger, and the Big Fat Deal is ready for the challenge. At a whopping 100mm wide, it can make the most of your fat bike footprint, for the ultimate in flotation over soft or powdery surfaces. At an incredibly light 500 grams per rim, the BFD is also much lighter than competitors’ skinnier aluminum rims. Combined with a tubeless tire setup, it is possible to lose up to two pounds per wheel with HED BFDs. Note that the BFD is drilled symmetrically ONLY and cannot accommodate offset frames.

Like the Big Deal, the BFD utilizes Inflatobam, HED’s patented tubeless technology for installing big tires. The twin channel rim design provides a better pre-inflation seal by trapping each tire bead against the rim. This drastically reduces the amount of air it takes to get the beads to “bam” into place. In conjunction with the rim shape, Inflatobam utilizes Inflatobands. These effectively provide a variable rim-channel diameter. This compensates for the discrepancies in tire bead diameters by minimizing the gap between the tire and the rim channels (the main source of air leaks). Once seated, the angled bead shelf prevents the tire from collapsing back into the rim at low pressure. Our interior surfacing and tight tolerances ensure no tire burp or slip. Also note that our rim shape does not require tire levers to remove and install tires.

Specifications

SKU: RI014
Rim Type: Tubeless-Ready Clincher
Rim Width: 100mm
Rim Material: Carbon
Rim Weight: 500 grams
Color: Twill Weave
Rim Hole Count: 32
MIN/MAX TIRE SIZE: 3.8 - 5.0"
Drill Pattern: Symmetrical Only
Decal Type: White
ERD: 564 (includes washer)
Rim Shape Patent #: 9597926

Tech Notes

1. Do NOT use tire levers on B.F.D. rims!
